Collection: Snow Plow Power Units
Magister Hydraulics offers a versatile solution for snow plow operators with two variants of hydraulic pumps. Choose between the 12V and 24V options to meet the specific power requirements of your snow removal tasks.
Some more features of Snow Plow Power Pumps
- Double-Acting Power Unit: Our double-acting hydraulic power unit is equipped with an 8-quart steel reservoir. This design ensures a sufficient amount of power to effortlessly handle the demands of snow removal tasks, providing operators with a reliable tool in challenging winter conditions.
- Adjustable Pressure Relief Valve: Prioritizing safety, the hydraulic power unit comes equipped with a pressure relief valve set at 2900 PSI. This valve not only acts as a safety measure but is also easily adjustable to accommodate specific requirements, offering peace of mind during operation.
- User-Friendly Design for Efficient Operation: The user-friendly design of Magister Hydraulics’ snow plow hydraulic pump facilitates both power up and power down applications, streamlining the snow plowing process for operators.
- The Double Over-Center Valve: This smart design feature acts as a guardian, protecting the hydraulic system in the presence of obstacles. This not only prevents potential damage but also extends the overall lifespan of power unit.
Snow Plow Power Unit Parameters:
- Action : Double Acting
- Max Flow : 1.85 GPM
- GPM @ 2500 PSI: 1.8 GPM
- Pressure : 2900 PSI
- Relief Valve :2900 PSI
- MAX RPM : 3500
- Pump Displacement :0.13 ci/rev
- Reservoir (QTs) : 8
- Tank Material : Steel
- Voltage :12 V, 24 V
- Current :Direct
- Motor Power :3 kW
- Port Size :SAE 8
Choose Magister Hydraulics for Winter’s Challenges
For a reliable, efficient, and durable solution to conquer winter’s icy challenges, choose Magister Hydraulics. Whether you opt for the 12V or 24V variant, rest assured that you’re equipped with a high-quality tool designed to handle the toughest snow removal tasks.
