WTG 1.5x16 | 1.5" bore x 16" stroke tang hydraulic cylinder

by Magister Hydraulics
SKU: WTG 1.5x16
$202.00
WTG 1.5x16 | 1.5" bore x 16" stroke tang hydraulic cylinder - HTX Fluid Power
WTG 1.5x16 | 1.5" bore x 16" stroke tang hydraulic cylinder
WTG 1.5x16 | 1.5" bore x 16" stroke tang hydraulic cylinder
WTG 1.5x16 | 1.5" bore x 16" stroke tang hydraulic cylinder
WTG 1.5x16 | 1.5" bore x 16" stroke tang hydraulic cylinder
WTG 1.5x16 | 1.5" bore x 16" stroke tang hydraulic cylinder
WTG 1.5x16 | 1.5" bore x 16" stroke tang hydraulic cylinder - HTX Fluid Power
Fast shipping

Fast shipping to the continguous 48 states.

Easy returns

We offer a 30-day peace of mind returns.

Need help?

Need help? 24/7 Dedicated support.

WTG 1.5x16 | 1.5" bore x 16" stroke tang hydraulic cylinder

by Magister Hydraulics
SKU: WTG 1.5x16
$202.00
SPECIFICATIONS
Bore 1.5 in
Stroke 16 in
Port Size SAE 6
Extended 41 in
Retracted 25 in
Overall length 26.4 in
Pressure 3500 PSI
Column Load 5,300 LBs
Oil Volume 0.49 QTs
Design Welded
Rod Type Chrome Plated
Rod End Narrow Tube
Action Double Acting
Weight 14 LBs
Brand Magister Hydraulics
GTIN 850016509079
Outer Diameter 1.88 in
Rod Diameter 1 in
Pin Diameter 0.75 in
